HANDLE BAR RIGHT SIDE
Ensure to turn ‘ON’ the engine cut-off switch before
starting the vehicle. Release the electric starter switch
immediately after pressing.
Note
1. Head lamp switch
Head lamp switch has two positions. Working of
switch at these positions are as followed:
OFF: The head lamp will be turned ‘OFF’ but
other lamps like DRL, speedometer back
illumination, tail lamp and number plate
lamp glows when the switch is positioned
at ‘ ‘ position with ignition ‘ON’.
ON: The head lamp low beam glows along
with all other lamps when the switch
is positioned at ‘ ‘ position with the
ignition ‘ON’. The headlamp high beam
can be obtained only after the engine
starting.
The DRL will act as a FPL once the headlamp is turned
‘ON’.
Note
2. Electric starter switch
Ensure the transmission is in neutral or else press
the clutch lever before engaging the electric starter
switch ‘ ‘.
3. Throttle grip
It controls the fuel-air mixture supplied to the engine,
which regulates the engine speed. Rotate the throttle
grip in counter-clockwise from its idle position to
increase the engine speed and vice-versa to reduce.
2
5
4
1
3
6
