34
INSTRUMENT CLUSTER
Your TVS Apache RTR 160 4V is provided with a fully
digital instrument cluster with lots of features and
various modes.
1. Speedometer
Indicates the vehicle speed in kilometer per hour.
2. Side stand indicator ( )
-NA-
3. Turn signal indicator right ( )
Flashes when the right side turn signal indication is
activated.
4. Immobilizer indicator ( )
-NA-
5. Low fuel indication ( )
Blinks when the fuel level reaches to minimum safe
level. It glows continuously when the fuel comes
below minimum safe level.
6. Neutral indicator lamp ( )
Glows when the vehicle is in neutral and goes ‘OFF’
if the gear is shifted from neutral.
7. High beam indicator lamp ( )
Glows when the head lamp is activated in high beam.
1
345678910
12
2
11
