62
Item
Service
km
Period from the date of sale
In free service After free service
Remarks
1st
500 - 750
1 month
2nd
2500 - 3000
3 months
3rd
5000 - 6000
6 months
4th
8500 - 9000
9 months
5th
11500 - 12000
12 months
Every
3000 km
3 months
Every
6000 km
6 months
Brake effectiveness I I I I I I –
Brake pedal shaft L L L L L L – Lubricate using TRU4 oil
Brake shoe
#
/ pad wear I I I I I I – Replace if necessary
Brake fluid I & T I & T I & T I & T I & T I & T –
WSS / toner ring I & C I & C I & C I & C I & C I & C – Replace if damaged
WSS cable clamps I I I I I I –
Fix new clamp if found
missing
WSS cable I I I I I I – Replace if damage
Brake hose / bundy tubes I I I I I – I Replace every 30000 km
Bundy tube mounting (all joints) I & TI I & TI I & TI I & TI I & TI I & TI – Inspect for leak
HECU mounting cushions – – I – I – I Replace every 30000 km
Toner rings teeth damage I I I I I I – Replace if necessary
Malfunction indicator lamp I I I I I I –
Check and resolve the errors
using diagnostic tool if the
lamp is ‘ON’ even after
starting the engine
Master cylinder cups – – – – – – – Replace every 21000 km
Wheel freeness I I I I I I –
Tyre pressure at cold condition I & S I & S I & S I & S I & S I & S –
#
Applicable for rear drum brake model Contd....
To Next Page
