LOCATION OF PARTS - HANDLE BAR
1. Connected instrument cluster
2. Ignition cum steering lock
3. Master cylinder (front)
4. Rear view mirror R
5. Engine cut off switch
6. Front brake lever
7. Throttle grip
8. Electric starter switch
9. Fuel tank cap
10. Horn switch
11. Turn signal lamp switch
12. Clutch lever
13. Pass by switch
14. Rear view mirror L
15. High / low beam switch
16. Info switch
2
1 3 4
8
11
161514
6
5
7
9
10
12
13
