18
Indicates the vehicle speed in kilometer per hour
by default whenever the ignition is turned ‘ON’.
This can be changed to mile per hour. Change the
mode between kilometer per hour and mile per hour
using the mode and set switch buttons (refer page
No. 29 for changing the speed indication between
km/h and mph).
2. Turn signal indicator right ( )
Flashes when the ‘right’ side turn signal indication is
activated.
3. Malfunction indicator lamp - MIL ( )
-NA-
If you leave the ignition key in ‘ON’ position and vehicle
is kept in gear without moving for more than 3 minutes,
an error message ‘CHECK SPEED SENSOR’ will scrolls
which is normal.
If you notice an error message ‘CHECK SPEED SENSOR’
while the vehicle is in move, Contact nearest TVS Motor
Company Authorised Main Dealer / Authorised Dealer
for rectification.
4. Low fuel indication ( )
Blinks when the fuel level reaches to minimum safe
fuel level. It glows continuously when the fuel comes
below minimum safe level.
5. Neutral indicator lamp ( )
Glows when the vehicle is in neutral and goes ‘OFF’
if the gear is shifted from neutral.
6. High beam indicator lamp ( )
Glows when the head lamp is activated in high beam.
7. ABS warning lamp ( )
ABS warning lamp blinks when the ignition key is
turned ‘ON’ and speedometer performing self check.
This lamp goes ‘OFF’ once the vehicle reaches
10 km/h speed and above in dual channel vehicle and
6 km/h speed and above in single channel vehicle. If
this lamp glows continuously then have your vehicle
checked at TVS Motor Company Authorised Main
Dealer / Authorised Dealer (refer page No. 04 for
more details).
8. Immobilizer indicator ( )
-NA-
9. Turn signal indicator left ( )
Flashes when the ‘left’ side turn signal indication is
activated.
NA - Not applicable for present model
