12
LOCATION OF PARTS - HANDLE BAR
1. Connected instrument cluster
2. Ignition cum steering lock
3. Master cylinder (front)
4. Mode switch
5. Rear view mirror R
6. Engine cut off switch
7. Adjustable front brake lever
8. Throttle grip
9. Electric starter switch
10. Fuel tank cap
11. Horn switch
12. Turn signal lamp switch
13. High / low beam switch
14. Adjustable Clutch lever
15. Rear view mirror L
16. Pass by switch
1 7. Info switch
2
1 3 54
9
12
171615
8
10
11
13
14
7
6
