11. Fuel gauge
Digital bars indicates the approximate quantity of
fuel available in the fuel tank. There are eight bars to
indicate the quantity of fuel available in the fuel tank.
All the eight bars will be displayed when the fuel
in the tank reaches above 10.5 liters approximately
(full tank). When the fuel reaches half tank (6.5 liters
approx.) the fuel gauge displays only four bars as
shown.
The fuel gauge shows only single bar when the fuel
reaches safe fuel level (3.5 liters approx.)
Before turning the IGNITION key to ON position, ensure
the availability of adequate fuel in the tank. That is LOW
FUEL INDICATION shall not come ON, before the start
of the vehicle.
To avoid dry run of fuel pump, never run vehicle
beyond 5 km, after LOW FUEL INDICATION.
Low fuel indication (serial No. 4) starts blinking when
the fuel reaches to the minimum safe level 2.5 liters
approximately. Refill the fuel immediately. Once the
fuel level reaches 1.8 liters approximately, no bar will
be visible and low fuel indication (serial No. 4) glows
continuously.
If all the fuel level bars in the cluster are blinking and
an error message ‘CHECK FUEL SENSOR’ blinks
at bottom, Contact nearest TVS Motor Company
Authorised Main Dealer / Authorised Dealer.
