Differential Oil level checking and topping up
Differential oil level can be checked with the help of oil level
checking bolt provided on cover differential.
● Park the vehicle on the level ground.
● Allow 5 to 10 min. for the oil to settle down.
● Unscrew the oil level check bolt using 10mm spanner
● The oil level is correct, if oil just starts flowing out when
the plug is removed.
● If not, oil level is less, top up with recommended oil, by
using special toll till the oil starts flowing out.
● To top up oil loosen filler bolt using 17mm spanner.
● Fill recommended oil by using special tool to fill and
tighten filler bolt with washer.
● Tighten the level plug with washer with out fail.
Tool name Tool size
Ring spanner, Socket spanner 10mm,17mm
Differential oil level checking and topping up
044
Self maintenance procedure
