● Refit drain plug along with plain washer and tighten it.
● Remove the dip stick and pour the correct quantity of
recommended oil by using special tool.
● Insert and tighten the dip stick completely.
● Check the oil level.
● Replace engine oil at every 10000 kms.
Tool name Tool size
Ring spanner 10 mm
Engine Oil Replacement
B
Self maintenance procedure
045
Engine Oil Replacement
● Run the Engine for a few minutes to warm up the oil
● Park the vehicle on level ground
● Allow some time for the oil to settle down.
● Place a oil pan under the drain plug and un-screw hex.
flange nuts (2nos.) and take out the cover oil strainer(B).
Also Remove 17 mm Magnetic drain bolt provided on the
crank case LH, and clean.
To Next Page
