Self maintenance procedure
LOW Engine Oil Pressure Indicator
● It is located on cluster assembly tell tale lamp as shown
in the figure.
● This indicator must glow in Ignition switch ON and
before starting the engine.
● It must switch off as soon as engine start ie., engine rpm
increases, or else bring the vehicle to authorized
distributor or dealer / authorized service center
CAUTION
Always use recommended transmission, differential
oil and special tool. Two different grade and brand of
oil should not be mixed
Engine oil pressure indicator
SPARK PLUG
Cleaning the spark plug
● Pull out the suppressor cap from the spark plug.
● Remove the spark plug by using plug spanner provided
in the tool kit.
● Clean carbon from the electrodes and around the base
with the help of spark plug cleaner.
● Adjust the gap to the specified limit if incorrect
● Spark plug should be replaced at every 10000km.
0.6- 0.7 mm
047
