Self maintenance procedure
048
Tool name 16 mm plug spanner
Spark plug Gap 0.6 - 0.7mm
Spark plug Type Bosch UR 6 DE
Spark plug cap Resistive
CAUTION
To adjust spark plug gap or replacement approach our
Distributor or Dealer / Authorized service center.
Plug the spark plug hole when the spark plug is removed
to avoid entry of foreign particles inside cylinder.
Always use recommended make and type of spark plug.
Changing tyres and wheels
1. Spare wheel removal
● Spare wheel is fitted to the Left Side chassis of the vehicle
below the load deck.
● Gently pull out the spare wheel cover, Remove the Spare
wheel lock using Key, then Loosen the spare wheel
mounting nuts along with spring washer using 17 mm
tubular spanner. ( 2nos.) ( A , B).
● Take out the spare wheel.
