Self maintenance procedure
NOTE
Mount the spare wheel on the bracket properly and tighten
the nuts thoroughly, close the spare wheel with cover.
Tyre and wheel changing procedure.
Removal
● Apply parking brake
● Loosen the wheel retaining nuts. (2 nos.)
● Take out the Jack & Rod from RH Side Utility Box.
● Place the jack as shown in the fig. (For removing front
wheel B (Cross Member ). rear wheel A. (Trailing Arm)
● Lift up the vehicle until the wheel clears the ground.
● Remove the retaining nuts and take out the wheel.
Spare wheel removal
049
Assembly
● While assembling the spare wheel tighten the wheel nuts
diagonally.
● Lower the vehicle slowly to the ground then tighten the
nuts fully to the recommended torque.
Tool name Tool size
Ring spanner, Socket spanner 17mm
Tyre Pressure
Load
Driver alone
(kerb with driver)
FR
30 30 30 50 45 60
FR FR FR FR FR
(Driver + 325kg) >(Driver + 400kg)
Laden - 400 kg
payload
Above - 400 kg
payload
Pressure
(psi)
