107
107
DESCRIPTION TVS APACHE RTR 160 (With Ride Mode)
CHASSIS
Kerb weight (with toolkit and 90% of
fuel)
138 kg
Pay load 130 kg
Maximum laden weight 268 kg
Steering angle 36° (both sides)
Caster angle 26 °
Frame Double Cradle Synchro STIFF
Front suspension Telescopic oil damped
Rear suspension
Monotube inverted gas filled 5 step adjustable
shocks (MIG) with rectangular swing arm
Trail length 81.3 mm
BRAKES
Front Hand operated, 270 mm petal Disc
Rear Foot operated, 200 mm petal disc
