• Clean the chain using soft brush.
• Repeat the steps if needed until the dust is
removed completely.
• Let the vehicle be parked for 10 ~15 mins to
ensure the chain is dry.
3. After the chain is completely dry, apply TVS TRU4
Chain Lub by rotating the rear wheel by hand in
forward direction.
4. Now, check the slackness of the drive chain (as
shown). The slackness of the drive chain should
not exceed the limit (maximum 20 ~ 25 mm).
Excess slackness consumes more fuel.
5. If the slackness is found more contact TVS Motor
Company Authorised Main Dealer / Authorised
Dealer for adjustment.
Lubricate the drive chain after the motorcycle is
washed with water or riding in rainy / wet condition.
The chain must be serviced more frequently when the
vehicle is operated under severe conditions like dusty,
muddy, wet, high speed or frequent starting / stopping.
Caution
FRONT WHEEL REMOVAL AND REASSEMBLY
1. Remove thes axle nut (1) along with a washer.
2. Pull out the axle (2) along with a washer.
3. Remove a spacer from the left side and toner ring
cover from the right side of the wheel.
4. Place a support below the frame to prevent
vehicle from falling and lift the vehicle up.
5. Carefully dislocate the disc from the caliper
assembly and slide the wheel out.
6. Reverse the procedure for reassembling.
1
2
