TVS RONIN - Location of Parts - Vehicle Front & Rear

22
LOCATION OF PARTS - VEHICLE FRONT & REAR
FRONT
1. Turn signal lamp front L
2. LED Head lamp assembly
3. Oil cooler
4. Tank guard
5. Position lamp
6. Turn signal lamp front R
REAR
1. Turn signal lamp rear R
2. Reflex reflector
3. Number plate lamp
4. Turn signal lamp rear L
5. Tail lamp assembly
6. Pillion handle
License plates are mandatory accessory will be charged extra
2
1
3
6
5
4
1
2
4
3
5
6
