In single channel ABS vehicle, the ABS warning lamp
will be blinking whenever the vehicle speed is less than
6 km/h during the ride which is normal. It indicates that
the ABS is working fine and no need of any inspection.
Note
10. ABS warning lamp ( )
ABS warning lamp blinks when the ignition key is
turned ‘ON’ and speedometer performing self check.
This lamp goes ‘OFF’ once the vehicle reaches
10 km/h speed and above in dual channel vehicle and
6 km/h speed and above in single channel vehicle.
If this lamp glows continuously even after reaching
the specified speed, have your vehicle checked at TVS
Motor Company Authorised Main Dealer / Authorised
Dealer (refer page no. 11 for more details).
11. Gear shift indicator / 12. Tachometer /
13. Digital clock / 14. Speedometer / 15. ODO -
TRIP A & B - DTE indicator / 16. Fuel gauge
Connected Type
Non-Connected Type
11
12
13
14
15
16
11
17
18
12
13
14
16
15
