INSTRUMEN PANEL - HANDLE BAR
Description :
1. Horn switch
2. Turn signal lamp switch
3. Clutch lever
4. Pass by switch (dimmer)
5. High / low beam switch
6. Rear view mirror L
7. Speedometer
8. Ignition lock
9. Instrument cluster
10. Brake master
11. Rear view mirror R
12. Engine stop
13. Front brake lever
14. Grip
15. Head lamp ON / OFF switch
16. Electric starter switch
17. Fuel tank cap
PANEL INSTRUMEN - SETANG
MENGENAL MAX 125 ANDA
16
13
1
2
3
17
15
14
11
6
7 8
9
10
4
5
12
KNOW ABOUT YOUR ZT 125
