4.3 Installation Method
♦ Clamping system
Table 1 Installation Method
Clamping
on the long
side
Installation Method A
Vertical to the Long Side, with Four Lock
Blocks
Installation Method B
Overlapping the Long Side, with Four Lock
Blocks
Clamping
on the
short side
Installation Method C
Overlapping the Short Side, with Four Lock
Blocks
Installation Method D
Vertical to the Short Side, with Four Lock
Blocks
Note: The length of the clamp≥50mm.
