♦ Installation with the mounting hole
Table 3 Installation Method
Installation Method E
Vertical to the Long Side, with Four Bolts
Installation Method F
Overlapping the Long Side, with Four Bolts
Clamping
on the
long side
Table 4 Mounting dimension and load capacity
Classification
Modules model
Height
of the
frame
(mm)
The mounting
clamp position
M(mm)
The mounting
clamp position
N(mm)
Installation Method E
Test load: front/back
（Pa）
Installation Method F
Test load: front/back
﹙Pa）
Monofacial
Module
TWMPD-54HS
TWMPD-54HB
TWMND-54HS
B30
990
1085
5400/2400
--
TWMPD-60HS
TWMND-60HS
B35
990
1085
±2400
--
1400
1085
5400/2400
--
TWMPD-66HS
TWMND-66HS
B35
990
1085
±2400
--
1400
1085
5400/2400
--
TWMPD-72HS
TWMND-72HS
B30
1400
1096
5400/2400
--
B35
990
1085
±2400
--
1400
1085
5400/2400
--
TWMPD-78HS
TWMND-78HS
B35
1200
1085
5400/2400
--
TWMPF-50HS
B35
1400
1055
5400/2400
--
TWMPF-55HS
B35
1400
1055
5400/2400
3600/2400
TWMPF-54HS
B35
1400
1262
5400/2400
--
TWMPF-60HS
B35
1400
1262
5400/2400
3600/2400
TWMPF-66HS
B35
1400
1262
5400/2400
3600/2400
