Tweco Spool gun - Model Specifications

SET-UP AND SAFE OPERATING PROCEDURES
2-5
89210007
SECTION 2:
MODEL SPECIFICATIONS
Description Rating
Rated Welding Current C0
2
160A
Duty Cycle 20%
Wire Diameter (Normal) 0.023-0.035 (Normal)
Wire Diameter (Stainless Steel) 0.023-0.030 (Stainless Steel)
Maximum Wire Feed Speed 630 in./min. (16 m/min.)
Maximum Wire Spool Size
Diameter: 4” (100 mm)
Width: 1.75” (45 mm)
Motor Voltage 24V DC
Model Specifications
