ASSEMBLY INSTRUCTIONS - CONTINUED
CORRECT BURNER INSTALLATION:
INCORRECT BURNER INSTALLATION:
The gas valve orifice is completely inserted inside the venturi.
The gas valve orifice is out of
position and is not inserted into the
burner.
The orifice is out of position. The
orifice is touching the tip of the
burner venturi.
