11
Figure 2-3 Side Opening
Fix the mounting base tothe ceiling with screws.
Figure 2-4 Fix the Mounting Base
Adjust the surveillance angel.
Loosen the tilt adjustingscrews, and adjust the tiltangel [0~65°],
and tighten the tilt adjusting screws.
Side Opening
