SPECIFICATIONS
T290/T300/T330
ENGINE
Four strokes, Direct injection, water-cooled
Diesel Engine.
Model : D1503-M
No. of cylinders :3
Swept Volume : 91.47 in³
Bore :3.26 in
Stroke :3.64 in
Compression Ratio :23:1
Horse Power (PS) :31
(Manufacturing rating)
Rated Speed :2,800 rpm
High idle rpm :3,000 rpm
Low idle rpm :850 to 950
Fuel injection pump : Bosch type mini pump
Cylinder sleeve :Dry
Air Cleaner : Dry Filter element,
paper element filtering type.
Exhaust Muffler : Horizontal Round.
Firing order : 1-2-3
Accelerator : Hand & Foot Accelerator
CLUTCH
Type : Dry single plate
Outer dia. X Inner dia. : 8.86 X 5.9″
TRANSMISSION
Type : synchro mesh
No. of gears :12 forward,
12 reverse gears
with high and low
selection lever with
Differential Lock
STEERING : Hydraulic power
(Power steering)
POWER TAKE OFF
Rear mounted : 6 splines
76
Accelerator : Hand & Foot Accelerator
ELECTRICAL STARTING AND LIGHTING
Battery Capacity : 12 Volt 110AH
Starter : Solenoid Engaged.
Key Start with Safety ,
starter switch
Alternator :12V 50A
Instrumentation :Water Temperature Gauge,
Taco meter, Hour meter,
Electrical fuel level gauge.
Lighting: Head lights, side indicators,
Rear parking,, brake &
indicator light, Front
parking & indicator light,
On dash board indicators
for battery charging, turn
signal, PTO signal, Engine
oil pressure, Preheat signal.
Rear mounted : 6 splines
Diameter : 1⅜ in.
Standard PTO : ①540/2,541 engine RPM
BRAKES
Foot operated, independent with provision of
inter lock for simultaneous operation. A foot
brake is fitted for parking.
Disc Diameter :6.22 in
Number of lining : 4 each side
Total brake thickness : 2.299 in
3 point linkage : category 1
adjustable outside
check chains.
