TYM T330 - Fault Tracing - Steering and Electrical; Steering Issues; Electrical Instrument Issues

▶ MAIN SPECIFICATIONS
Model T290/T300/T330
Dimensions
Overall length (mm) 3290 (129")
Overall width(mm) 1320 (52")
Overall height(mm) 2360 (92")
Distance between shafts(mm) 1640(64")
Tread(mm) Front 1067 (42")
Rear 1029~1345
(40.5”~52.9”)
Least ground clearance (mm) 330 (13")
Weight (kg) 1390(3064 lbs)
Engine
Name D1503-M
Type
Water cooled 4 cycle
diesel engine
Displacement (CC) 1499
Output/speed(PS/rpm) 31/2800
Fuel Diesel fuel
Traveling Speed
Linear Sub
shift
Main
shift
Forward
(mile/h)
Reverse
(mile/h)
F
(R)
L 1 0.55 0.53
2 0.75 0.73
3 0.96 0.94
4 1.33 1.30
M 1 1.72 1.68
2 2.37 2.30
3 3.04 2.96
4 4.20 4.08
H 1 5.50 5.35
2 7.55 7.34
3 9.71 9.44
4
13.41
13.03
77
Fuel tank capacity 33L(8.7US gal)
Starting system
Starting with motor
Tire Front 7-16-4 PR
Rear 11.2--24-4PR
Body Clutch system Dry single type
Braking system Wet disc type
Steering system Hydraulic
Diff system Bevel gear(Diff-lock)
Shift method Synchromesh
Minimum turning radius(m) 2.5(98")
Shifting stages Forward 12 stages
Reverse 12 stages
PTO Shaft (mm) Ø35, 6splines
Lifter Control Position control
Mounting CAT 1 type
4
13.41
13.03
