TECHNICAL SPECIFICATIONS

INSTALLATION

Note the

portion of

strip that is

cut-off is

no longer

usable.

12V DC

• Choose your desired location.

( – see suggestions above)

• Clean surface thoroughly with

isopropyl alcohol. Dry completely.

• Peel off the 3M™ tape backer and

carefully apply to the desired area.

Note:

• For use with 12V power only

• Suitable temperature for

installation is 70°F (21°C) or above.

• If needed LED strips can be cut – ONLY

cut where scissors mark is shown.

Working voltage: DC 12V Only

Bluetooth distance:

No obstacle 30ft

Frequency band: 2.4GHZ

Types of LED:

5050 SMD RGB

Maximum LED: 20ft (total combined)

Maximum amperage draw: 3A
