FLIGHT CONTROLS (TEAM MODE)
15
17
18
19
20
21
22
16
01
02
03
05
07
04
06
14
08
10
09
11
12
13
PILOT WIZARD™ CAMERA OPERATOR ST16
Tilt Control Buon-up
Start / Stop Motors Buon
Wizard™ Power Buon
Wizard™ Power LED
Smart / Angle / Home Mode Switch
Pan Mode：
- Follow
(yaw can’t be controlled)
- Follow Controllable
- Global
10
11
12
13
14
15
Aircra Mode LED
Wizard™ GPS LED
Aircra Status LED
Turn / Fly to the Le Side Buon
Ascend / Forward Buon
Magic Buon
Turn / Fly to the Right Side Buon
Descend / Backward Buon
Tilt Control Buon-down
01
02
03
04
05
06
07
08
09
Gimbal Tilt Slider in Angle
Tilt Mode:
-Angle/Velocity
Gimbal Tilt Control in Velocity Mode (Mode 1)
Take Sll Photo Buon
Gimbal Pan Control in Global
Follow Controllable mode
Tilt Control in Velocity (mode 2)
Start/Stop Video Recording Button
16
17
18
19
20
21
22
