4-7
Section 4 - Parts
Item Part No. Part No. Part No. Description
Black White Stainless Steel
1 80-17072-01 80-17072-02 80-17072-03 Door Assembly, RH
N/A N/A 80-17072-13 Door Assembly, LH
2 23025 23025 23025 Nameplate
3 26070-01-S 26070-02-S N/A Handle Assembly
4 42173-BLK 42173-NAT N/A Hole plug (included with handle assembly)
5 12094-01 12094-03 12094-02 Gasket, door
6 12095-07 12095-08 12095-09 Gasket, vertical
7 11901-1-BLK-S 11901-1-BLK-S 11994-BLK-S Pivot plate
8 42161-ZP 42161-ZP 42161-ZP Screw, pivot plate
9 11898-S-BLK 11898-S-KIT 11995-S-SS Hinge Assembly, top
10 11899-S-BLK 11899-S-KIT 11996-S-SS Hinge Assembly, bottom
11 31673-S 31673-S 31673-S Door Closer Assembly
12 42101-BLK 42101-ZP 42101-SS Screw, hinge (included with hinge assembly)
13 42096 42096 42096 Pivot post (included with hinge assembly)
14 41604 41725 N/A Screw, handle (included with handle assembly)
15 80-29010-01 80-29010-02 80-29010-03 Grille
16 20033-BLK 20033-ZP 20033-ZP Screw (included with grille)
17 12095-01 12095-03 12095-02 Gasket, horizontal
18 31690 31690 31690 Door Shelf
19 N/A N/A 14160-01 Towel Bar Handle Assembly
20 11969-02 11969-02 11969-02 Back panel
21 41342 41342 41342 Screw, back panel
22 31317 31317 31317 Light bulb, 10W, 120V
23 2891-01 2891-01 2891-01 Light Socket Assembly
24 31696 31696 31696 Shelf
25 70078-S 70078-S 70078-S Compressor
26 2819 2819 2819 Process tube (included with 70078-S)
27 2693 2693 2693 Dryer (included with 70078-S)
28 31021 31021 31021 Grommet (included with 70078-S)
29 71011 71011 71011 Overload (included with 70078-S)
30 71012 71012 71012 Relay (included with 70078-S)
31 70078-CAP 70078-CAP 70078-CAP Cover (included with 70078-S)
Not 41978 41978 41978 U-Line Cleaner (6 applications per order)
Shown
Not N/A N/A 14159-01 Commercial handle (SS accessory only)
Shown
CLRCO2175 (1 of 4)
