PAGE 3 OF 9 0222 IH-10001
MOUNTING
1. Using provided drill bit, drill hole into the concrete,
block or stone to a depth of 2½". (See Inset A)
2. Blow out the dust in the hole.
3. Place bracket over tubing.
4. Secure screw flush with bracket into drilled hole.
(See Inset B)
5. Repeat on remaining screws.
2/"
Inset A
Inset B
