U-Line H-6513 - Specifications

PAGE 3 OF 9 0217 IH-6513
SPECIFICATIONS
FEATURES
PARTS
MODEL NO.
H-6513 H-6514
BTU/HR
135,000 190,000
FUEL CONSUMPTION (GAL/HR)
1.00 1.42
FUEL TANK CAPACITY (GAL)
10.0 13.0
PUMP PRESSURE (PSI)
5.5 8.5
VOLTS (AC/Hz)
120VAC/60Hz 120VAC/60Hz
AMPS
2.3A 2.7A
PHASE
Single Single
Fuel Tank
Lamp
Drain Plug
Power
Cord
Side Cover
Fuel Cap
Fuel Gauge
Lower Shell
Hot Air Outlet
Front Handle
Upper Shell
Rear Handle
Fan Guard
Side Cover
Digital
Temperature
Display
Power/Reset Switch
Thermostat Knob
50 mm
Screw x 4
Front Handle x 1 Wheel Support Frame x 1 Rear Handle x 1 Axle x 1
30 mm
Screw x 8
8 mm
Nut x 12
Wheel x 2 Axle Nut x 2 Spacer x 2 Spare Drain
Plug x 1
