Rev08/04/2015
Parameter Description 5 PANS 115V 5 PANS 230V
SELF CONTAINED 230V
TROLLEY
PR2 declared power connected to relay2 [num] 0
0 0 0
PR3 declared power connected to relay3 [num] 0
0 0 0
PR4 declared power connected to relay4 [num] 0
0 0 0
PR5 declared power connected to relay5 [num] 0
0 0 0
PR6 declared power connected to relay6 [num] 0
0 0 0
PR7 declared power connected to relay7 [num] 0
0 0 0
PR8 declared power connected to relay8 [num] 0
0 0 0
STB number of cycles during D test [num] 5
5 5 5
CYC number of on7off cycles during D test [num] 5
5 5 5
WIN max pull down time in winter D test [num] 90
90 90 90
SUM max pull down time in summer D test [num] 120
120 120 120
ETT set point in heating cycle during D test [°C/°F] 59 59
59 59
SPU user set point in storage cycle [°C/°F] 37 37
37 37
OF1 cabinet probe offset [num] -0.7
-0.7 -0.7 0
OF2 evaporator probe offset [°C/°F] 0 0
0 0
OF3 condenser probe offset [°C/°F] 0 0
0 0
OF4 core probe point 1 offset [°C/°F] 0 0
0 0
OF5 core probe point 2 offset [°C/°F] 0 0
0 0
OF6 core probe point 3 offset [°C/°F] 0 0
0 0
OF7 core probe point 4 offset [°C/°F] 0 0
0 0
OF8 core probe point 5 offset [°C/°F] 0 0
0 0
SLL not used -40
-40 -40 -40
SLH not used 3
3 3 3
RHU cabinet RH% set point settable [num] 80
80 80 80
MNS mains voltage alarm limit [%] 20
20 20 20
MAL voltage alarm delay [hours] 10
10 10 10
MEV max number of voltage conditions before voltage alarm [num] 5
5 5 5
