PAGE 8 OF 18 0518 IH-6323
DIAGRAMA DE PARTES INTERIORES
Cabezal de
Impresión
Red Superior
(Espacio) Sensor
de Matriz
Soportes para
Rollo
Guías para Papel
Rodillo Portapapel
(Guía)
Sensor Móvil
(Línea Negra y Red/Espacio Bajo)
Sensor del Cabezal
(interior)
Detención de
Guía del Papel
Ajuste
