SKU 93644 For technical questions, please call 1-800-444-3353. Page 2
PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operat-
ing, inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep this manual and invoice in a safe and dry place for future reference.
UNPACKING
When unpacking, check to make sure all the parts shown in the Parts List on page 8
are included. If any parts are missing or broken, please call Harbor Freight Tools at the
number shown on the front cover of this manual as soon as possible.
GENERAL SAFETY RULES
IMPORTANT SAFETY INSTRUCTIONS
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions detailed in this manual may
result in serious personal injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered and dark work areas invite
accidents.
Pressure Scale 0<->1000 PSI / 0<->7000 kPa
Gauge 2-9/16” Diameter / 2-5/8” Bezel Diameter / 1-1/8” Deep
Air Release Type Thumb Button Release
Maximum Working Pressure 1000 PSI
Hose Size 15/64” I.D. / 35/64” O.D. / 16” Long
Accessories Carrying Case
Weight 3.50 Pounds
