TRIPLE PLAY SPOTTER
Item Ref. No. Qty Description
1 17 10 Nut-Nylon Lock-Ss-10-32
2 18 1 Nut-Hex Nyl Loc Ss 4-40
3 21 4 Screw 10-32 X 5/8 Socket
4 22 7 Fhp-10-32 5-8
5 24 3 Washer-Flat-Ss-10
6 28 3 Screw-Php-Ss-4x3/8-Sms
7 30 1 Screw 10-24 X 1/2 Hex Hea
8 35 1 Tie 4 Black Weather Resis
9 90 1 Elbow 90 Brass1/8 Fm .X 1/
10 97 2 Bushing Pipe 1/4 Male Pipe X
11 265 2 Washer Buna 11/32 X .0625 Thick
12 267 6 Screw-Php-Ss-6x1/2-Sms
13 357 2 Washer 7/16 An Flat Ss
14 374 1 Quick Disconnect Plug 1/8 K
15 384 1 Hose Barb Brass 1/8 Mpt X 1/
16 385 8 Hose Clamp 1/4 X 5/8 X 7/16 Wi
17 386 3 Scr-Flt Phil Ss 10-32 X 4.00
18 390 3 Nut-Hex Machine 10-32
19 408 1 Vac Motor, 120v
407A 1 Vacuum Motor 5.7 240 V 2- (SPOTTER-240)
20 416 0.75” Tubing Tefl on 3/16 Id X .03
21 440 1 Flange Exhaust Black Polypr
22 981 1 Gasket Tank 11-1/2 X 8-3/1
23 984 1 Power Cord 18/3 Sjtw 25 B
2019 300” Powercord European Color Code (SPOTTER-240)
24 986 1 Plate Bottom Cover Spotter
25 990 2 Bracket L For Spotter Pump
26 994 1 Plate-Mounting-Vacuum-Spotter
27 996 25.5” Hose Braided 1/4 Id Clear
28 996 16” Hose Braided 1/4 Id Clear
29 996 10.5” Hose Braided 1/4 Id Clear
30 996 22.5” Hose Braided 1/4 Id Clear
31 999 2 Filter 40 Mesh S/S 1/4 Npt
32 1000 4 Hose Barb 90 Deg Nylon 1/8 Mpt
33 1117 4 Scr-Pan Phil 8-32 X .25
34 2013 1 Gasket 1 Side Adhesive 5-1/2 O
35 56471194 2 Latch Assembly
36 56750746 1 Nipple, 1/8npt X .75
37 56755726 2 Barb, Hose Male
38 230A 1 Nut-Lock-Nylon
39 230USP 1 Retainer Power Cord Water T
40 27AUSP 2 Axel Cap Black Pal Nut
41# 306AB 3 Washer-Flat-Hh-Brass-7/8odx.412idx1/16 Thick
42
315A 1 Screw-Php-Ss-Zp-4-40x3/4-Ms
43 39857A 2 Wheel 5 X 1.50 X .500
44 988B 1 Valve 3-Way For Spotter & Apc
45 989USP 1 Pump 55 Psi 120v For Spotter
989A 1 Pump 55 Psi W/ Viton Seal For (SPOTTER-240)
46 FP454 1 Holding Tank Spotter-Black (SPOTTER, SPOTTER-240, SPOTTER-B)
56381319 1 Holding Tank-Spotter Mold KB (SPOTTER-DZ)
56381360 1 Holding Tank-Spotter Mold TEAL (SPOTTER-S)
47 987 1 Switchplate Spotter
48 2123 1 Switch Rocker Dpst W/Light 120
48G 1 Switch Rocker Spst W/Light 230 (SPOTTER-240)
49 325 6 Nut-Nylon Lock-Ss-8-32
50 808 1 Screw 6x3/8 S/S Trusshead P
51 980 1 Gasket Vacuum Seal 2.9 X 6
52 983 1 LID And RING 4 LID CLEAR
53 1074B 1 Gasket-Lid-Xlpe-4.5idx3/16 Thick
54 21C 5 Screw-Php-Ss-8-32x5/8
55 325C 4 Bolt-Php-Ss-8-32x1/2
56 382C 1 Screw 8-32 X 7/8 Panhead Phi
57 805USP 1 Chain-Cover
58 909A 2 Latch-Strike-Ss-No 8 Hole
59 56381341 1 Vac Tank-Spotter Mold Wht
56381684 1 Vac Tank-Spotter Mold Red (SPOTTER-B)
# = Revised or new since last update
revised 11/13
1/10 D - 3 56041856 - SPOTTER
PARTS LIST
