U-tec Ultraloq Lever User Manual

- 3 -
Installation Video
Please watch our easy step by step installation video before attempting to
install your Ultraloq Lever Fingerprint and Touchscreen Smart Lock.
Or you can also view the website directly.
www.u-tec.com/lock/lever/guide
Installation Guide
1. Preparing the Door
Check the door’s dimensions.
Step 1
Measure to confirm that the door is between 1
5
/
16
” ~ 2 ” (33 mm-50 mm) thick.
Step 2
Measure to confirm that the diameter of the hole is 2
1
/
8
” (53 mm).
Step 3
Measure to confirm that the backset is either 2
3
/
8
” or 2
3
/
4
” (60 mm or 70 mm) .
Step 4
Measure to confirm that the diameter of the hole in the door edge is 1” (25 mm).
2
3
/
4
”
2
3
/
8
”
(70 mm)
OR
(60 mm)
1” (25 mm)
(33 mm-50mm)
1
5
/
1 6
” 2”
-
2
1
/
8
”
(53 mm)
1”
25 mm
53 mm
2
1
/
8
”
(70 mm)
(60 mm)
(53 mm)
(70 mm)
(60 mm)
(53 mm)
