5 Ubee DVW32CB – Safety and Installation Product Insert v1.0
Wall-Mount Installation
You can mount the device on a wall using the 2
mounting brackets on the bottom of the device.
We recommend that you use two round or pan
head screws.
1. Install two screws horizontally apart on a wall
using the measurement shown to the right.
The screws should protrude from the wall so
that you can fit the device between the head
of the screw and the wall. If you install the
screws in drywall, use hollow wall anchors to
ensure that the unit does not pull away from
the wall due to prolonged strain from the cable
and power connectors.
2. Remove the device from the product package.
3. Mount the device on the wall.
4. Refer to the following figure.
The Distance of the Pothook (Horizontal)
The Screw’s Size (mm)
163mm
(
6.4 inches
)
A
B C
A 6.65+/-0.35
B 1.9+/-0.15
C 19.0+/1.20

Ubee DVW32CB Specifications

General

DOCSIS Version	3.0
Downstream Channels	8
Upstream Channels	4
Ethernet Ports	4
Ethernet Speed	10/100/1000 Mbps
USB Ports	1
Telephony Ports	2
Maximum Data Rate	343 Mbps
Wi-Fi Frequency Bands	2.4 GHz
Security Features	WPA, WPA2
Wi-Fi Standard	802.11a/b/g/n/ac
