Hardware Pack 2
Part Description Part No Quantity Image
BB M6 Flat washer UD06C 16 pcs
EE M6 Nut LM06C 8 pcs
FF M6*40 Screw SM06040C 8 pcs
JJ ￠20 Flat washer UAD06C 1 pc
Fig. 4: Attach middle beam down connector (G) to beam with bolt (CC) and flat washer (II).
Fig. 5: Attach long mosquito net rail (N) to long side beam, attach short mosquito net rail (O) to short beam
with bolt (CC) and flat washer (II).
