Uberhaus 72255106 - Page 11

Page 11
Step 5
G1
G
F2
G
G1
G
V
V
G1
5.1. Insert one end of the Connector (F2) inside of the Lintel (G) such that the holes from both pieces
align. Fix them together using Screws (V).
5.2. Insert the other end of the Connector (F2) inside of the Lintel (G1) such that the holes from both
pieces align. Fix them together using Screws (V). Make sure the Screws are well tightened.
