Uberhaus 72255157 - Page 6

Step 1:
E
F
I
I
X
X
X
X
X
X
1. Attach the Bracing Bar (I) to the Left Lintel (E) and the Right Lintel (F) with the Bolt (X).
(Pay attention to the direction of the Bracing Bar (I) during assembly.）
G
H
X
X
X
X
X
X
G
X
X
X
X
X
X
H
2. Attach the Bracing Bar (H) to the Middle Lintel (G) with the Bolt (X). (Pay attention to the
direction of the Bracing Bar (H) during assembly)
Step 2:
R
E
F
I
I
E
R
3. Insert the Left Lintel (E) into the Outer Connector (R).
E F
P
U
U
U
U
4. Attach the Left Lintel (E) and the Right Lintel (F) to the Connector (P) with the Bolt (U).
Page 6
