Uberhaus 72255162 - Page 12

14. Insert Short Bar (4) into Bolt (34) of Lower Central Connector (2), and tighten Bolt (34).
See Fig.14
15. Attach underside of Short Bar (4) to Connection Piece (9) with Bolt (33). See Fig.15
Page 12
Fig.14
Fig.14
Fig.15
Fig.15
Fig.15
(3)
(3)
(3)
(3)
(2)
(4)
(4)
(9)
(5a)
(5a)
(5a)
(6)
(6)
(3)
(33)
(3)
(3)
(4)
(4)
