UE Systems ULTRAPROBE 10000 Instructions

TQC Work Verify
Ultrasound Ultraprobe 10,000 Instructions
Valve Inspection ABCD Sometimes E Method:
Rev. 1.0 3/2012 SAFETY: Wrist Strap to be Worn at ALL TIMES
2-5 min
UE Systems Training
*Compact Flash Card & Module Inserted BEFORE Turning Ultraprobe ON*
Push Sens.Knob 1X more to return cursor to S=
(Operational Home Spot for Adjusting Sensitivity).
17
Note Approximate Test Points for the ABCD,
sometime E Method of testing Valves.
18
NOTE: Choose Test Point A for the Valve
19
Store Record: Adjust Sens. for dB reading of
Position A,Once Stored, A dB appears in position
'A' and advances to 'B.' Repeat for position B,C,D.
20
Page 5 of
6
