Ultima NEO - Micro Current and IFT Specifications

The will appear on your screen if this formula is not
followed in EMS manual mode.
Micro Current:
Frequency: 94Hz fixed(P1), 80Hz fixed(P2),
0.5,8,80Hz(M)
Pulse width: 250μs fixed(P1), 2ms fixed(P2,M)
Wave form Mono-Phase rectangular,
Symmetrical Bi-Phasic rectangular
Treatment timer Continuous, 10, 20, 30, 45, 60, 90min
Interferential(IFT):
Carrier Frequency 4000Hz fixed (P1,M-CH1) ,
8000Hz fixed (P2-CH1)
Modulating Frequency 4150Hz fixed (P1-CH2)
8160Hz fixed (P2-CH2)
4000-4150Hz(M-CH2)
Pulse width 125μs
Wave form Symmetrical balanced Sine wave
Treatment timer Continuous, 10, 20, 30, 45, 60,
90min
