03
WING ASSEMBLY
Procedure 1
Procedure 2
Procedure 3
Try to move the Aileron up and down. Leave about 0.5-1.0 mm
gap between the wing and the aileron. This gap is also named
as "hinge line" which will be used in the following procedure.
You must allow the aileron control surface to move freely. Use
CA on the Hinge to hold the Aileron position.
Carefully remove the covering material on the holes with a sharp hobby knife.
C.A
To Next Page
