Page #21 background image
II
Check Dust seal & bearing
(6004RS) for proper fitment &
smooth rotation.
Replace if found worn
out/noisy.
Remove right bush rear wheel
& Panel rear brake carefully
from rear wheel.
CLEAN HUB INNER SURFACE
& BRAKE LINEAR SURFACE
BEFORE REFITTING.
REPLACE BRAKE SHOES IF
FOUND WORN OUT OR
HARD.
REPLACE HUB IF INNER
SURFACE FOUND WORN
OUT.
SERVICE LIMIT
1-HUB id-131 mm.
2-Brake liner thickness-3
mm
