16
-SIDE & MAIN STAND
Check that both the sta
nds are
smooth in function.
Check spring for proper
fitment
&
Apply Grease if hard in
operation.
Central stand is tightened
with-
1.
central stand axle L=130-
2.
washer Φ16
3.
spring pin
Side stand is tightened with-
Hexagon flange bolt
M10*1.25-
35
-
42
44
