Service Manual

Housing Assembly Diagram

ITEM # Description

01 PLATE, WINDOW

02 HINGE, A’SSY, SUN

03 SCREW, TCT, A, 4DX7, NI

04 SCREW, TCT, A, 3DX7, NI

05 HOUSING, SUN, UCCXXX

06 PANEL, LOGO, UTA-3A

07 PAD, PVC, 21, 5X6, UTA-V

08 TAPE, 10MM, DS-31
