Introduction
11/48
Reference air pressure
The reference atmospheric air
pressure is conducted to the
pressure transducer via the air
permeable (white) Teflon
membrane and through the
cable.
Sealed cable
The T5 can
be completely buried
if required. If buried cables
should be protected
Sensor body
The incorporated piezoelectric
pressure sensor measures the
soil water tension against
atmospheric pressure.
Acrylic glass shaft
Shafts are available with
lengths from 2 to 20 cm
High grade porous ceramic cup
Filled with degassed water.
