TONNEAU INSTALLATION GUIDE
(866) 900-8800 www.undercoverinfo.com
UNDERCOVER WALL HANGING INSTRUCTIONS
A
C
D
B
32”
70”
Model 1010 Chevy Silverado, GMC Sierra 1999–Current
Page 10
FORM # IG1010
Modified April 2005
Prior to removing the
tonneau, mount the two J-Hooks
provided on the garage wall. The hooks
must have a minimum height from the
floor of 70”, and be 32” on center
horizontally apart
Picture A & B.
Remove your tonneau from
the truck bed according to instructions
on page 9, 1-Minute Removal.
Hang tonneau vertically on
the wall-mounted J-Hooks, with the
underside against the wall inserting
J-Hooks into the holes provided in
Picture C.
Step 3
Step 2
Step 1
