UNGARO FAGIOLO PLUS - Page 5

5
INSTALLATION AND OPERATION MANUAL
inform the user on how to use the heating
system and provide technical documenta-
tion for the appliances used in the installa-
tion. The installer must ll in:
• Heating system booklet
• Documentation for the installation
The technical documentation includes:
• Reference to the current standards;
• Manufacturers installation indications;
• A rough description or scheme, or photo-
graphs of any system modications made;
• Compliance Certicate;
• The date and the installer’s signature.
A sign upon receipt of the technical
documentation is requested from the
user.
3.3 Installation Area
The stove should be positioned on the re
resistant oor. If the ooring is made of
ammable material, provide a oor pro-
tection surface in compliance with current
national standards. Respect the safety cle-
arance as shown on g. 2.
Ungaro S.r.l. will not accept any
liability in case of re for failure to
comply with the safety clearance.
C
A
B
Flammable
Materials
Non ammable
Materials
A 500 mm 200 mm
B 500 mm 200 mm
C 1500 mm 1500 mm
g. 2 - Safety clearance
3.4 Heating and ductable air fans
The stove has two fans for forced air he-
ating. The standard conguration for both
fans is frontal outlet, heating the room of
installation. According to the factory stan-
dard, the upper fan can be used for ducta-
ble air heating in the remote room. The fan
can be spinned positioning the hot air outlet
backwards, see the precut indicated on the
g.3. Then must the ductable ait function
must be activated in the control panel. This
modication can be made only by an au-
thorized technician. It’s recommended to
bring the ductable air pipe not longer than
8 linear meters in a single destination.
Ductable air outlet N 1
Ductable air outlet N 2
Smoke outlet
Primary air entrance
412,5
133
245
136
267
261
1118,5
128,5
g. 3 - Ductable air outlets
3.4 Flue Pipe
(ref. UNI 10683)
The ue pipe must meet the following re-
quirements:
• Twin wall steel ue, required diameter
is 100 mm round;
• It must be resistant to heat, mechani-
cal stress, heat, combustion residues
and related condensate;
• It must be installed at a safe distance
from eventual combustible materials;
• It must have draft between 11 and 15
