Inductance measurement:
2 mH ± (2.0% + 10) @ 1 µH ,
20 mH ± (2.0% + 10) @ 10 µH ,
200 mH ± (2.0% + 10) @ 0.1 mH ,
20 H ± (3.0% + 10) @ 10 mH
Frequency measurement: 2 kHz ... 10 MHz ± (0.1% + 3) @ 1 Hz (automatic range change)
Temperature measurement:
• °C
-40 ... 0 °C ± (3% + 4) @ 1 °C
0 ... 400 °C ± (1% + 3) @ 1 °C
400 ... 1000 °C ± (2% + 10) @ 1 °C,
• °F
-40 ... 32 °F ± (3% + 4) @ 1 °F
32 ... 752 °F ± (1% + 4) @ 1 °F
752 ... 1832 °F ± 2.5% @ 1 °F
hFE:
Diode test:
Sound signal of the continuity test:
Checking TTL logic states:
RS-232:
Main features:
• Large, readable LCD display with backlight
• Aesthetic and solid construction
Power supply: 9V, type 6F22 battery - included
Dimensions: 205 x 101 x 60 mm
Manufacturer / Brand: UNI-T
Guarantee: 2 years
