7 operation
1 Select polarity
Inspect the terminal device to establish the
polarity that is required, or consult the op-
erating instructions of the terminal device.
Positive polarity Negative polarity
outer
–
/ inner + outer + / inner
–
Move the polarity selector switch on your
mains adapter to the relevant position (see
following illustrations).
Positive polarity – selector switch down:
